| made my own Intake system | |
|---|---|
| Tweet Topic Started: Jul 28 2010, 03:53 PM (1,267 Views) | |
| TYdakota4x4 | Jul 28 2010, 03:53 PM Post #1 |
|
Senior member
![]() ![]() ![]() ![]() ![]() ![]()
|
I made a nice looking intake system. i used 3 inch manderal intake tubing by vibrant. and used some couplings but i had to cut the piping down to size. i kept the stock air box because it keeps stuff and water out and i got a drop in K&N filter. Let me know what you think or what i should do to improve. |
![]() 2002 Dodge Dakota QuadCab 4x4 4.7 V8 Magnum. Mods. 3" body lift, cranked torsion bars, 2 inch rear blocks, 265/70/R16 Nitto Terra Grapplers, K&N Filter, Flowmaster 40 series, custom intake | |
![]() |
|
| ffighter530 | Jul 28 2010, 05:03 PM Post #2 |
|
No this is the Dakota Quad Squad!
![]() ![]() ![]() ![]() ![]()
|
I'm not quite sure if this is completely correct or not, and please someone correct me if I'm wrong. I believe the two most restrictive parts of the intake are that big silencing box that sits on top of your engine(which you replaced) and the air box itself. Instead of getting a drop-in filter I would have got a K&N cone and clamped it to the end of your intake tube. I attached a picture of my intake, I think you could pull off essentially the same thing just without the housing around the filter. Anyways, awesome work with the tubing I wanted to actually paint my K&N tube to match my truck but I never got around to it.
|
![]() |
|
| ffighter530 | Jul 28 2010, 05:04 PM Post #3 |
|
No this is the Dakota Quad Squad!
![]() ![]() ![]() ![]() ![]()
|
and how much did it cost you to make the actual intake part of it, minus the filter? Just wondering |
![]() Justin | |
![]() |
|
| TYdakota4x4 | Jul 28 2010, 07:16 PM Post #4 |
|
Senior member
![]() ![]() ![]() ![]() ![]() ![]()
|
i dont remeber exact but the tubing was $55 and the cuplings were around another 15 so around 70-80. i juss didnt like the fact of using pvc piping on my truck so i went this route. |
![]() 2002 Dodge Dakota QuadCab 4x4 4.7 V8 Magnum. Mods. 3" body lift, cranked torsion bars, 2 inch rear blocks, 265/70/R16 Nitto Terra Grapplers, K&N Filter, Flowmaster 40 series, custom intake | |
![]() |
|
| The Cook | Jul 28 2010, 07:49 PM Post #5 |
|
Techfo Guru
![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]()
|
Greetings Group I'd lose the factory air box cover and pull the rubber dam off the passenger rad side to help force air in. Drop in K&N is good but like Fire said, go for the conical style filter......if you still have the factory splash guard in your front wheel wells don't worry about water and mud getting to your filter............there are some good snaps and info about intakes under our search site.......check it and keep the questions coming Regards as always ![]() TC |
![]() |
|
| TYdakota4x4 | Jul 28 2010, 07:59 PM Post #6 |
|
Senior member
![]() ![]() ![]() ![]() ![]() ![]()
|
so i guess i am going to buy a cone intake but what do i do with the tube that goes to the stock airfilter box |
![]() 2002 Dodge Dakota QuadCab 4x4 4.7 V8 Magnum. Mods. 3" body lift, cranked torsion bars, 2 inch rear blocks, 265/70/R16 Nitto Terra Grapplers, K&N Filter, Flowmaster 40 series, custom intake | |
![]() |
|
| ffighter530 | Jul 30 2010, 04:28 PM Post #7 |
|
No this is the Dakota Quad Squad!
![]() ![]() ![]() ![]() ![]()
|
oh wow nice pricing though. definitely cheaper than a kit. anyways if you're talking about the tube that goes from the bottom of the air box to the wheel well, that should easily come out with the air box. i wondered if anyone else has this, but when you installed a full aftermarket intake, removing the resonator your intake makes such an awesome noise when you're really on the gas. almost like a vrrooom but instead of blowing exhaust, its sucking air. lol if your reading this you're probably like I love the way my engine sounds with the aftermarket intake.
|
![]() |
|
| TYdakota4x4 | Jul 30 2010, 08:39 PM Post #8 |
|
Senior member
![]() ![]() ![]() ![]() ![]() ![]()
|
no im talking about the vaccum line that is connect to the stock air box thats why i left it stock with a k&n Cone filter because i need to find how to connect that back or put a little filter on the vaccum line |
![]() 2002 Dodge Dakota QuadCab 4x4 4.7 V8 Magnum. Mods. 3" body lift, cranked torsion bars, 2 inch rear blocks, 265/70/R16 Nitto Terra Grapplers, K&N Filter, Flowmaster 40 series, custom intake | |
![]() |
|
| TYdakota4x4 | Jul 30 2010, 09:02 PM Post #9 |
|
Senior member
![]() ![]() ![]() ![]() ![]() ![]()
|
im just going to get a 3/8 rubber grommet and drill a hole in the intake tubing for the vaccumm line |
![]() 2002 Dodge Dakota QuadCab 4x4 4.7 V8 Magnum. Mods. 3" body lift, cranked torsion bars, 2 inch rear blocks, 265/70/R16 Nitto Terra Grapplers, K&N Filter, Flowmaster 40 series, custom intake | |
![]() |
|
| burganb | Aug 18 2010, 07:37 AM Post #10 |
|
Country Kota
![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]()
|
You right that the air hat is more restrictive due to the silencer cutout that the factory puts in the air hats. However, the airbox is not as restrictive as most seem to believe. The nice thing about the factory sustem is that it actually pulls cold air from somewhere (ie in the fender). With most CAI on the market they pull more hot engine air than cold air or they have verystrange area of location to pull supposed cold air. Great example is the K&N system. They conical flows great, but its filtration suck and the box ends right in front of the PCM. Where is it supposedly pulling its cold air from, the fender behind the PCM? Oh by the way guys if you want performance like a K&N but you want the 99.4% filtration rate (vs the low 90s% filtration rate). R2C Performance makes a high flow, reusable/cleanable dry filter. You just have to send them your dimensions of the cone you need. |
|
2001 Dodge Dakota QC 4x4 4.7L SOLD 2004 Toyota MR-S CURRENT | |
![]() |
|
| SPC.Brinkmeyer | Dec 9 2010, 01:10 AM Post #11 |
![]()
you cant fix STUPID,,, stupid
![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]()
|
got any pix of anyone making one on a 3.7 |
![]() 04' QC 4WD, 285/75/16 BFG's________________________________________________________________________06' 300C SRT8 | |
![]() |
|
| Verrucktwolfq | Feb 16 2011, 10:47 AM Post #12 |
|
Advanced Member
![]() ![]() ![]() ![]() ![]()
|
Where did you get the bent piping to do this? Was it available to be bought like this or did you have a shop make it? |
![]() |
|
| TYdakota4x4 | Feb 21 2011, 05:30 PM Post #13 |
|
Senior member
![]() ![]() ![]() ![]() ![]() ![]()
|
i got the bent piping from a local performance shop . the piping is actually for intakes. they piping is called vibrant piping. |
![]() 2002 Dodge Dakota QuadCab 4x4 4.7 V8 Magnum. Mods. 3" body lift, cranked torsion bars, 2 inch rear blocks, 265/70/R16 Nitto Terra Grapplers, K&N Filter, Flowmaster 40 series, custom intake | |
![]() |
|
| Verrucktwolfq | Feb 22 2011, 06:40 AM Post #14 |
|
Advanced Member
![]() ![]() ![]() ![]() ![]()
|
Thanks for the info. I'll have to look into what I have around here. |
![]() |
|
| 04dak | Mar 2 2011, 12:20 PM Post #15 |
|
Mobile Mamogram Machine
![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]()
|
wheres is your IAT at? any gains from this so far? |
![]() Branden 04'QC, 4.7 Lots Of mods, 4.56's Cardomain site lytlebranden@hotmail.com | |
![]() |
|
